Chat with our Expersts - Live SKU: 1.25G BiDi SFP
Vat Included
Only 50 Left in stock
Minimum Order Quantity: 1 Piece
Key Features
* Hot pluggable SFP MSA form package, SFP MSA compliant
* Comply with Ethernet/SDH/SONET transmission standard
* Single LC or SC receptacles
* Low power consumption
* I2C management interface, Built-in digital diagnostic functions
* Supports a variety of transmission distances from 500m to 120km
* RoHS compliant
* Operating temperature range: 0~70°C(Commercial) /-40~85℃(industrial)
Read More Less
The 2.5Gbps Single fiber bidirectional SFP series optical transceiver supports a variety of transmission distance from 500m to 120km, the series of products use a single LC or SC optical interface, with low power consumption, small size, high reliability, wide temperature range, and other characteristics. It is mainly used in Ethernet/SDH/SONET transmission environments.
| P/N | Data Rate | Wavelength | Reach | Connector | Tx Power | Rx Sensitivity | Source |
| YV-GE-3T/R | 1.25Gbps | 1310/1550nm | 3km | BiDi LC/SC | -9~-3db | ≤-21db | FP+PIN |
| YV-GE-3T/R-3149 | 1.25Gbps | 1310/1490nm | 3km | BiDi LC/SC | -9~-3db | ≤-21db | FP+PIN |
| YV-GE-20T/R | 1.25Gbps | 1310/1550nm | 20km | BiDi LC/SC | -9~-3db | ≤-23db | FP+PIN |
| YV-GE-20T/R-3149 | 1.25Gbps | 1310/1490nm | 20km | BiDi LC/SC | -9~3db | ≤-23db | FP+PIN |
| YV-GE-40T/R | 1.25Gbps | 1310/1550nm | 40km | BiDi LC/SC | -5~3db | ≤-26db | DFB+PIN |
| YV-GE-40T/R-3149 | 1.25Gbps | 1310/1490nm | 40km | BiDi LC/SC | -5~3db | ≤-26db | DFB+PIN |
| YV-GE-80T/R | 1.25Gbps | 1490/1550nm | 80km | BiDi LC/SC | -2~3db | ≤-28db | DFB+APD |
| YV-GE-120T/R | 1.25Gbps | 1490/1550nm | 120km | BiDi LC/SC | -1~4db | ≤-30db | DFB+APD |
| YV-GE-160T/R | 1.25Gbps | 1490/1550nm | 160km | BiDi LC/SC | -1~4db | ≤-32db | DFB+APD |
