2.5G BiDi SFP

SKU: BiDi SFP

( 0 ) Reviews


Please make a enquiry or Get Quote
0

Key Features

* Hot-pluggable SFP MSA form package, SFP MSA compliant
* Comply with Ethernet/SDH/SONET transmission standard
* Single LC or SC receptacles
* Low power consumption
* I2C management interface, Built-in digital diagnostic functions
* Supports a variety of transmission distances from 500m to 120km
* RoHS compliant
* Operating temperature range: 0~70°C(Commercial) /-40~85℃(industrial)




Read More Less

The 2.5Gbps Single fiber bidirectional SFP series optical transceiver supports a variety of transmission distance from 500m to 120km, the series of products use a single LC or SC optical interface, with low power consumption, small size, high reliability, wide temperature range, and other characteristics. It is mainly used in Ethernet/SDH/SONET transmission environments.

P/N Data Rate Wavelength Reach Connector Tx Power Rx Sensitivity Source
YV-2GE-3T/R 2.5Gbps 1310/1550nm 3km BiDi LC/SC -10~-3db ≤-18db FP+PIN
YV-2GE-3T/R-3149 2.5Gbps 1310/1550nm 3km BiDi LC/SC -10~-3db ≤-18db FP+PIN
YV-2GE-20T/R 2.5Gbps 1310/1550nm 20km BiDi LC/SC -5~0db ≤-18db DFB+PIN
YV-2GE-20T/R-3149 2.5Gbps 1310/1490nm 20km BiDi LC/SC -5~0db ≤-18db DFB+PIN
YV-2GE-40T/R 2.5Gbps 1310/1550nm 40km BiDi LC/SC -2~3db ≤-19db DFB+PIN
YV-2GE-40T/R-3149 2.5Gbps 1310/1490nm 40km BiDi LC/SC -2~3db ≤-19db DFB+PIN
YV-2GE-80T/R 2.5Gbps 1490/1550nm 80km BiDi LC/SC -2~3db ≤-28db DFB+APD
YV-2GE-120T/R 2.5Gbps 1490/1550nm 120km BiDi LC/SC 2~5db ≤-30db DFB+APD

Imaging

2.5G BiDi SFP P/N Data Rate Wavelength Reach Connector Tx Power Rx Sensitivity Source YV-2GE-3T/R 2.5Gbps 1310/1550nm 3km BiDi LC/SC -10~-3db ≤-18db FP+PIN YV-2GE-3T/R-3149 2.5Gbps 1310/1550nm 3km BiDi LC/SC -10~-3db ≤-18db FP+PIN YV-2GE-20T/R 2.5Gbps 1310/1550nm 20km BiDi LC/SC -5~0db ≤-18db DFB+PIN YV-2GE-20T/R-3149 2.5Gbps 1310/1490nm 20km BiDi LC/SC -5~0db ≤-18db DFB+PIN YV-2GE-40T/R 2.5Gbps 1310/1550nm 40km BiDi LC/SC -2~3db ≤-19db DFB+PIN YV-2GE-40T/R-3149 2.5Gbps 1310/1490nm 40km BiDi LC/SC -2~3db ≤-19db DFB+PIN YV-2GE-80T/R 2.5Gbps 1490/1550nm 80km BiDi LC/SC -2~3db ≤-28db DFB+APD YV-2GE-120T/R 2.5Gbps 1490/1550nm 120km BiDi LC/SC 2~5db ≤-30db DFB+APD
