PM2 is a dynamic microphone that uses electromagnetic induction to vibrate and produce sound. Its mission is to bring musicians' microphones out of the recording studio and to better serve people's entertainment life! PM2 is a noise-reduction microphone using USB and XLR ports, and it is connected to terminals such as computers and mobile phones via USB data cables.
At the same time, PM2 is also a piece of studio-level professional equipment. Connect the mixer through the XLR output interface. Let the PM2 embark on a sound journey with you!
Mi.AUDIO Control Software: https://relacart.com/pc/Support/Tool&Software/toolsDetail?id=d7bf88e44547044e444b245435f31faf&language=en
|Relacart PM2 Functional Features:||Real-time monitoring The microphone volume can be monitored in real time through the 3.5mm headphone jack to ensure perfect audio output. Wide compatibility PM2 can be connected via USB, including mobile phones (iOS, Android) and computers (Windows), as well as audio equipment such as mixers via XLR. Anti-interference PM2 skillfully uses PM2's metal bracket, microphone noise reduction and Relacart Midudio's application program to achieve noise reduction and sound insulation on both the microphone itself and the program ends, so that your wonderful voice can be protected from external interference and achieve triple protection! Standalone application With the relacart miaudio tuning, when connected via USB, it can be easily recognized by the relacart miaudio application (computer and mobile). The built-in DSP processor can adjust the microphone gain, microphone mute, balance, monitor mixing, clipping and compression. The PM2 can also be connected to professional audio devices via XLR. A variety of sound effect Users can set a variety of different sound effects on the Relacart Miaudio application. Even novices who do not understand tuning can easily try, which enables PM2 to play more wonderful sounds. Convenient operation PM2 has a built-in touch panel, which is convenient for directly adjusting the volume of the microphone. You can slide to adjust the microphone gain, headset volume, monitor mixing, mute the microphone, lock the touch screen, etc.|
There are 6 small knobs on the top of the M1 panel:
TRE, MID, BASS knobs are for manually adjusting the tone of your voice from the microphone.
The PITCH knob is for adjusting the pitch of the 4 voice-changer modes and HOST, SING, OST 3 sound modes.
The MUSIC knob is for adjusting the volume of accompanying music (this includes Bluetooth music and wired input music from the MUSIC port).
MONITOR is for adjusting the volume of the headphones and speaker. 2 large knobs.
REVERB adjusts the reverb/echo effects of your voice from microphones.
OUTPUT is for adjusting the output audio volume to PHONE or PC ports.
In the middle of the bottom half of the panel, there are 3 slider knobs. The left slider is for adjusting the volume of MIC L group (MIC L1, MIC L2). The mute button is for mute the two mics. The right slider and right mute button are doing the same for MIC R group (MIC R1, MIC R2). The middle slider is for adjusting the volume of instrument.
The red +48V button has nothing to do with the INST slider. The +48V button is the on/off 48V phantom power. It will add 48 volts to the left and right mics (MICL1 and MIC R1). MIC L1 port and MIC R1 port are for 48V condenser microphones. Only when you open red +48V button, the two MIC ports will start work. MIC L2 and MIC R2 are for 5V condenser microphones or dynamic microphones. The microphones in our bundles are condenser. If you want to use your own dynamic mic, you need to switch MIC SETTING to dynamic.
Hi-Res Audio Certified: The D1 headphone is certified for high-resolution audio, delivering exceptional sound fidelity. Its powerful 50mm neodymium driver ensures clear and crisp sound, providing an immersive listening experience.
Wide Frequency Range: The headphone's wide frequency range spans from 10 Hz to 38 kHz, enabling you to enjoy both high and low soundtracks with immersive clarity.
Dual-Connector Cable: The D1 headphone offers versatility with both a gold-plated 6.35mm plug and a 3.5mm port. This dual-connector setup allows you to connect to various devices, including musical instruments like electric guitars. The included 4-meter coiled audio cable is flexible, durable, and resistant to kinking, twisting, or breaking during normal use. It's compatible with a wide range of equipment, such as soundboards, karaoke machines, phones, laptops, Chromebooks, and other audio devices.
Comfortable Earmuffs & Noise Reduction: Designed for comfort and sound isolation, the leather foam-filled ear pads ensure a comfortable fit during extended listening sessions. The noise reduction design enhances your immersion in the audio experience by minimizing external distractions.
Foldable Design: The earmuffs of the D1 headphone are designed to rotate, offering free-style and single-side monitoring options. They can also be flipped up to adapt to the shape of your head for a perfect fit. Additionally, the foldable design allows the headphone to neatly fit into bags or laptop cases for easy portability.
Adjustable Hinge and Angle: The adjustable headband features 7 levels of adjustment, providing impressive flexibility to ensure a perfect fit according to your preferences and attire.
Note: Microphone stand and shock mount excluded
The bundle includes a specially designed microphone boom arm and mic shock mount. These accessories provide superior stability and isolation, ensuring minimal handling noise and vibrations. Unlike traditional mic stands and shock mounts, our product focuses on clean aesthetics and symmetry, creating an artistic presence once properly set up. The 5 small cable holders are strategically placed to neatly conceal the microphone cable within the gap between the dual arms, enhancing the overall appearance of your desktop setup.
With our microphone bundle, you'll enjoy professional-grade audio capture, versatile microphone options, and a visually pleasing setup that complements your workspace. Whether you're a content creator, podcaster, or musician, this bundle provides the perfect combination of performance and aesthetics for all your recording needs. Elevate your audio recordings to new heights with our exceptional microphone bundle.
Note: Microphone stand and shock mount excluded
The microphone bundle includes a specially designed microphone boom arm and mic shock mount. Unlike traditional mic stands and shock mounts, our product stands out with its unique design and attention to detail. When properly set up, it becomes a captivating piece of artwork, aligned perfectly with the popular aesthetic sense of symmetry. By incorporating five small cable holders, we offer a practical solution to neatly conceal the microphone cable within the gap between the dual arms. This thoughtful design significantly enhances the appearance of your desktop, creating a clean and polished look.
Experience professional audio quality and elevate your recording setup to new heights with the STU1+ 48V Cardioid Condenser Microphone. Discover the perfect balance of technical excellence and artistic design, and bring your creativity to life with stunning precision and aesthetic appeal.
