The Sun is the limit
ZOLAR® professional LED lighting system is developed by Shenzhen ImagineVision Technology Limited, the same successful team that created Z CAM Cinema Cameras. ZOLAR® products are developed with profound color science knowledge, leading image processing algorithms, as well as camera lens and sensor calibration expertise. Delivering high-fidelity color reproduction and excellent color rendition with performances very close to natural daylight.
Our in-house developed “Self Adaptive Spectral Nonlinear Dynamic Illuminance Calibration System” eliminates inconsistent LED performance issues. In addition, our revolutionary solution allows a mixture of the ZOLAR® light series to be used simultaneously without any visible color deviation (color matching mode will be added to other ZOLAR® series).
ZOLAR® Toliman is a Bi-color LED light panel series targeting professional video productions. Its excellent soft light performance and high-fidelity color reproduction have set a new benchmark for the industry. Designed with dual full spectrum LEDs to deliver continuous light spectrum across full CCT range with exceptionally high CRI & TLCI scores, particularly in R9, R12, R13 & R15. No compromise.
Spectral Similarity Index (SSI) is developed by The Academy of Motion Picture Arts and Sciences to evaluate the fidelity of color reproduction, particularly for LED light, from a single-chip CMOS digital camera point of view. It quantitatively compares the spectrum of the test light with that of a desired reference light source, expressing the similarity as a single number on a scale up to 100. High values indicate a high likelihood of high-fidelity color reproduction by most cameras. SSI of ZOLAR® Toliman is close to or exceeds 90, across the full CCT range (3,200K~5,600K), a leading standard in the industry.
A higher score implies higher fidelity in color reproduction, particularly skin tone. This is exactly why these scores exist.
·CRI: Ra ≥ 97 (R9 & R12 up to 95), TLCI ≥ 98;
Spectral Similarity Index SSI up to 90;
Low power consumption high output: Input ≤ 120W, Output ≥ 4,680 lx at 1m / 3.28ft;
Revolutionary 25o optical design lens array to boost illuminance.
ZOLAR® Stylist precision directional super light transmissible panel: control beam angle, light diffusion, no color shift;
Multi Light Sync - ZolarLink (wireless), rapid auto sync grouping;
Supports Art-Net 4 & sACN (through wireless connection)
Built in video effects for different scene applications
Bluetooth + WiFi mixed control: Remote Controller, mobile app (iOS & Android)
Disclaimer: All product features and technical specifications stated are subjected to Z CAM’s sole interpretation and explanation. Specifications are subject to change without notice.
| Brand | ZOLAR® |
| Series | Toliman |
| Model | 30S |
| LED Type | Bi-color, Full Spectrum |
| White Light | 3,200K to 5,600K continuously variable correlated color temperature |
| Light Diffusion System | 25° lens array + ZOLAR® Stylist |
| Color Rendition | CRI: Ra ≥ 97 (R9 & R12 up to 95), TLCI ≥ 98 |
| Spectral Similarity Index | SSI up to 90 |
| Light Aperture | 250mm x 250mm (9.84" x 9.84") |
| Dimming | 0 ~ 100 % continuous (Main Unit Controller 0.1% precision), different dimming curves, smooth dimming down to zero without color shift. |
| Color Temperature Tolerance | +/- 100 K (nominal) |
| Tilt Angle | ± 360° |
| Handling | Aluminium Yoke, Tilt Lock Clamping Lever, Pole Operation for pan & tilt |
| Mounting | 16 mm / 28 mm Combo Pin (Baby 5/8" / Junior 1-1/8" Combo Pin) / 28 mm Spigot (Junior Pin) |
| Multi Light Sync | ZolarLink™ - Multi Light Sync Protocol, up to 16 groups with 60 slave units maximum per group (wireless). |
| Control | Main Unit Controller |
| Remote Controller | Remote Controller, cable length 5m (16.4 ft) |
| Wireless Control | WiFi, Bluetooth, ZOLAR® Mobile App, Art-Net 4 & sACN protocol |
| Power Input | 36V, 4.16A DC |
| Power Input | Male 3-Pin XLR - 15A (Pin 1: Negative / Pin 2: Positive) |
| Battery Input | V-Mount, 12.8~16.8V |
| Power Consumption | 140 W maximum |
| Cooling System | Low Noise Fan mode (Auto, High, Mid, Low) |
| Ambient Temperature Operation | -20ºC ～ +45° C (-4ºF ～ +113°F) |
| Estimated LED Lifetime | 50,000 hours (L70) |
| Estimated Color Shift Over Lifetime (CCT) | '+/- 5% |
| Weight (Main Unit) | 4.36 kg / 9.61 lb (Main Unit + ZOLAR® Stylist W) |
| Weight (Main Unit) | 5.22 kg / 11.51 lb (Main Unit + ZOLAR® Stylist W + Yoke) |
| Weight (Full Package) | 9 kg / 19.84 lb (Main Unit + ZOLAR® Stylist W + Yoke + AC DC Power Adapter + Remote Controller + Packing Materials) |
| Measurements (HxWxL) | 475 x 420 x 157 mm / 18.70 x 16.54 x 6.18 inch (Main Unit + Yoke) |
| Measurements (HxWxL) | 580 x 535 x 245 mm / 22.84 x 21.06 x 9.65 inch (Full Package) |
| Certifications | CE, FCC, SRRC |
